Specifications
- Digital Control System
- advanced technology uses 32-bit Digital Signal Processor
- Waveform Generator
- Internal waveform generator up to 500Hz
- Function type: ramp, sine, triangular or square
- State of the art signal conditioning
- Plug and Play Transducer like Load Cell, Extensometer etc.
- 24 bit signal conditioning, ±10.000.000 steps.
- 2.5 Khz to 10kHz data acquisition
- Provision for Up to 14 (slots) for data acquisition of transducers.
- All channels are synchronous and simultaneous.
- Excellent control
- Position, Load and Strain Control
- PID Control System
- 10kHz loop closure
- Adaptive Control
- Input and Output
- Digital Input 8 No’s 24V
- Digital Output 8 No’s 24V
- PC Interface
